    FL500 UV/IR Flame Detector


    FL500 UV/IR Flame Detector

    • Proven Technology. UV/IR flame detection uses an ultraviolet and an infrared detector to monitor for flames by measuring two different flame spectrums
    • Detection and False Alarm Reliability. FM approved detection performance. Excellent false alarm immunity, preventing unwanted shutdowns.
    • FM Performance Approved. Seven fuel sources – heptane, methane, methanol, propane, ethane, butane, hydrogen. See the FL500 performance simulator:
    • Wide Field of View. 130° cone of vision covers greater area, with a maximum detection range of 27 meters, reducing the number of detectors required
    • Safety Integrity Self-Check. Continuous Optical Path Monitoring (COPM) performs self-check every two minutes to ensure the optical path is clear and the electronic circuitry is functional.
    • Test Anytime, Anywhere. Easily test with our TL105 Test Lamp that allows the FL500 UV/IR Flame Detector and the entire system to be safely tested under real fire conditions with a simulated flicker of a flame.
    • Withstands Extremes. Wide operating temperature range (-55°C to +85°C) permits operation in extreme environments
    • Status at a Glance. Three LED status indicators for warning, alarm, and normal operations
    • Rugged Housing. Red powder coated 316 stainless steel housing to withstand the harshest environments
    • Multiple Output Options. Industry standard 4-20 mA (source or sink analog), Modbus, HART, relays
